Name: China Customized Fluidized Bed Furnace Manufacturers Suppliers Factory - Wholesale Service - Haike
Brand: Haike
SKU: 300837929

The HKF series fluidized bed furnace is a preferred equipment for drying materials in many industries in China. It uses a fluidized bed combustion method. Fuel is blown by high-pressure air and boils like a fluid. This gives strong combustion.

Send Inquiry

Product Introduction

A Top Choice for Drying Heat Sources

The HKF series fluidized bed furnace is a preferred equipment for drying materials in many industries in China. It uses a fluidized bed combustion method. Fuel is blown by high-pressure air and boils like a fluid. This gives strong combustion. The fluidized bed furnace has high combustion efficiency, stable furnace temperature, sufficient heat supply, simple manufacturing, easy operation, flexible adjustment, and big energy savings. It is an ideal heat source for drying systems in building materials, chemical, metallurgy, and power industries. Jiangsu Haike Environmental Tech Co., LTD has 28 workers and a 30-acre factory. We are a high-tech company with many patents.

Eight Core Features of This Furnace

First, good fuel adaptability. It can burn almost any low-grade coal like coal gangue, middling coal, and low-grade bituminous coal. Second, fuel burns fully with over 99% burn rate, saving over 40% coal compared to manual stoves. Third, fuel preparation is simple. Coal only needs to be crushed to 0-8 mm. Fourth, high automation, fast heating, and long pressure holding time. Fifth, automatic overflow slag discharge with good activity for mixing. Sixth, heat efficiency is 2-4 times other types, giving stable 450-1200°C hot air. Seventh, low pollution with much lower SO and CO emissions. Eighth, a dust collection device inside for clean material.

Technical Data for Fluidized Bed Furnace

Combustion efficiency is 95%. Flue gas temperature is 850±50°C. Coal size is ≤10mm. Full data (disk feeder, bucket elevator, etc.) available from engineer.

Name	Heat Supply (Kj/h)	Coal Use (kg/h)	Fan Air Flow (m³/h)	Dimensions (m)
HKF250	2.9-3.8×10⁶	110-150	5000	5.0×3.1×4.0
HKF450	1.0-2.0×10⁷	400-450	10000	6.0×4.0×4.6
HKF550	2.4-2.6×10⁷	1000-1100	15000	6.5×4.2×5.0
HKF850	3.4-3.6×10⁷	1400-1500	20000	6.8×4.5×5.0

Case from Sichuan Mineral Powder Plant

A mineral powder plant in Sichuan used a manual coal stove. It burned a lot of coal every day. The temperature was not stable. The dried powder quality was uneven. We replaced it with a HKF450 fluidized bed furnace. Now they save nearly half the coal each day. The temperature is very stable. The powder quality is consistent. The customer said this furnace was worth it.
