Sand And Gravel Classifier

Name: China Customized Sand And Gravel Classifier Manufacturers Suppliers Factory - Quotation - Haike
Brand: Haike
SKU: 300841649

Our Sand and Gravel Classifier is a core machine for sand and gravel production lines, including crushing and sand making. It sorts sand and gravel by particle size. It can also remove powder, mud, and water.

Send Inquiry

Product Introduction

Core Machine for Sand and Gravel Lines

Our Sand and Gravel Classifier is a core machine for sand and gravel production lines, including crushing and sand making. It sorts sand and gravel by particle size. It can also remove powder, mud, and water. This helps you meet different requirements for construction, concrete, and road building. Jiangsu Haike Environmental Tech Co., LTD has 28 workers and a 30-acre factory. We are a high-tech company with many patents since 2014.

Dry Process, No Water Pollution

Traditional sand washing uses a lot of water. It also produces sludge that is hard to treat. Our Sand and Gravel Classifier is a dry process. It uses no water. There is no waste water discharge. It is perfect for dry areas and places with strict environmental rules. It removes excess stone powder from manufactured sand. One customer in Fujian had stone powder content of 15% in their sand. That was too high for construction standards. We installed an HKX800 classifier. The stone powder content dropped to below 5%. They passed the test easily.

Technical Data for Sand and Gravel Classifier

Fan models range from SCF-No.8C to SCF-No.20B. Full data is available.

Model	HKX500	HKX600	HKX700	HKX800	HKX900	HKX1000	HKX1100	HKX1200
Capacity (t/h)	60	90	120	150	200	300	400	500
Motor Power (kW)	7.5-11	11-15	15-18.5	18.5-30	30-37	37-55	55-75	75-90
Fan Power (kW)	30	37	55	75	132	160	200	220
Speed (r/min)	190-380	150-350	150-350	150-350	140-350	100-300	100-300	100-300

Case from Fujian Sand Plant

A sand plant in Fujian made manufactured sand. But the stone powder content was too high for construction standards. We installed an HKX800 Sand and Gravel Classifier. It removed the excess powder using air. The stone powder content fell from 15% to below 5%. Their product passed the required test without any problem.
